Product Details:
Payment & Shipping Terms:
|
Application: | Data Cables , Lan Cables , High Frequency Cables , Power Cables | Structure: | Cantilever Type |
---|---|---|---|
Bearing: | NSK Or China Famous Brand | Color: | Decided By User |
Twist Direction: | S / Z Optional | Take Up Type: | Shaft Lever Type |
Highlight: | double twist bunching machine,cable bunching machine |
Wire And Cable Twisting Machine Cantilever Frame Structure Data Single Twister
1. Application
Data cables
Lan cables
High efficiency cables
Power Cables
It's suitable for power wire, CAT 5 and ultra CAT 5 and 6 data cable, communication cable and other special high speed twist, and also taping etc..
2. Technical Parameter
Model | 630 | 800 | 1000 | 1250 |
Rotate speed | 850rpm | 600rpm | 500rpm | 400rpm |
Bobbin dia. | 630mm | 800mm | 1000mm | 1250mm |
Finished OD | 3-10mm | 3-15mm | 3-20mm | 10-25mm |
Pitch range | 25-180mm | 30-200mm | 40-250mm | 40-300mm |
Twist direction | S/Z optional | |||
Take up type | Shaft lever type | |||
Control system | PLC auto control system |
3. Less Bending
Three wire through pulleys , less bending and damage on twisted cable , ensure good electrical performance.
4. Auto Oiling Device
With setting oiling period and time time on PLC. Oiling device will also auto process, makes machine more durable.
5. Bobbin Traversing Take up
Fixed traversing wheel, movable bobbin for traversing and take up, pitch setting according to finished OD, compact ranking without pressure.
6. Picture for reference
